Epson TM-m30II User Manual

28
Chapter 2 Setup
Installing the Printer
You can install the printer on a flat surface with the paper eject from top or with the paper eject from the front.
Place the printer on a flat surface.
Top eject position
Front eject position
• Take measures to prevent the printer from moving due to vibrations when using the cash drawer.
• Do not place the printer in locations subject to high dust levels.
• Do not give a high impact on the printer during operation. Doing so may cause the print failure.
• Be careful not to place cords or foreign substances under the printer.
• You can install the printer as a wall hanging printer if you use the optional Wall Hanging Bracket
Set (OT-WH30). Refer to the installation manual of the Wall Hanging Bracket Set for details.
• When you have set the printer to eject printed paper from the front side, you can flip printed
pages upside down by enabling the "Batch rotate print (Upside Down)" function. For more
details, see "Software Settings" on page 47.

Epson TM-m30II Specifications

General

Type	POS printer
Character sets	ANK
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum roll diameter	83 mm
Supported paper width	58 mm - 80 mm (Breite) mm
Maximum printing width	80 mm
Power plug type	Type G
Power source type	AC
USB port	Yes
USB connector	USB Type-A / USB Type-B
USB 2.0 ports quantity	2
Connectivity technology	Wired
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	No
Internal memory	- MB
Built-in barcodes	-
Country of origin	Philippines
Mounting position	Horizontal/Vertical
Autocutter durability	1.5 million cuts
Built-in sensors details	Paper End Sensor, Papier-Sensor
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	360000 h
Product color	White
Print head life	150.000.000 Impulse
Mean cycles between failures (MCBF)	65000000
Pre-installed software	TMNet WebConfig, ePOS-Device, ePOS-Display, ePOS-Print
Package depth	240 mm
Package width	200 mm
Package weight	2150 g
Quantity per pack	1 pc(s)
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Master (outer) case weight	0 g
Harmonized System (HS) code	84433210
Quantity per master (outer) case	4 pc(s)

Weight and Dimensions

Width	127 mm
