37
Chapter 2 Setup
Connecting to the Power Source
Connecting the AC cable
1
Make sure the printer is turned off.
2
Connect the AC cable to the AC adapter.
3
Connect the DC cable of the AC adapter to the power supply connector.
WARNING
Be sure to use the specified AC adapter (AC adapter, C1) only.
Never insert the AC cable plug into a socket that does not meet the input voltage of the AC
adapter.
Doing so may result in damage to the printer.
Should a fault ever occur, immediately turn off the power to the printer and unplug the AC
cable from the socket.
When disconnecting the DC cable of the AC adapter from the printer, make sure that the AC cable is
not connected, and then hold the arrow-printed portion of the connector to pull it straight out.
Arrow-printed portion of the connector
AC cable
AC adapter

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson TM-m30II and is the answer not in the manual?

Epson TM-m30II Specifications

General IconGeneral
TypePOS printer
Character setsANK
Print technologyDirect thermal
Maximum resolution203 x 203 DPI
Maximum roll diameter83 mm
Supported paper width58 mm - 80 mm (Breite) mm
Maximum printing width80 mm
Power plug typeType G
Power source typeAC
USB portYes
USB connectorUSB Type-A / USB Type-B
USB 2.0 ports quantity2
Connectivity technologyWired
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)5 - 45 °C
Operating relative humidity (H-H)10 - 90 %
Wi-FiNo
Internal memory- MB
Built-in barcodes-
Country of originPhilippines
Mounting positionHorizontal/Vertical
Autocutter durability1.5 million cuts
Built-in sensors detailsPaper End Sensor, Papier-Sensor
Sound pressure level (printing)55 dB
Mean time between failures (MTBF)360000 h
Product colorWhite
Print head life150.000.000 Impulse
Mean cycles between failures (MCBF)65000000
Pre-installed softwareTMNet WebConfig, ePOS-Device, ePOS-Display, ePOS-Print
Package depth240 mm
Package width200 mm
Package weight2150 g
Quantity per pack1 pc(s)
Quantity per pallet128 pc(s)
Quantity per pallet (UK)192 pc(s)
Master (outer) case width400 mm
Master (outer) case height255 mm
Master (outer) case length490 mm
Master (outer) case weight0 g
Harmonized System (HS) code84433210
Quantity per master (outer) case4 pc(s)
Weight and Dimensions IconWeight and Dimensions
Width127 mm
