Epson TM-m30II User Manual

56
Chapter 3 Advanced Usage
Network Settings
The following explains the procedure for network settings in order to connect the product to your network.
Setup methods
There are three methods for set up.
Method 1: Setup using EpsonNet Config
This method involves installing the network configuration tool, EpsonNet Config, on your computer for
setting.
As it does not require any settings in advance to allow set up, you can easily perform set up using a computer
already connected to the network.
Download EpsonNet Config from the Epson website.
Method 2: Setup using EpsonNet Config (Web version)
This method involves opening the Web application equipped in the printer from a Web browser to perform
settings.
Because you specify the printer's IP address to open it, you need to set your computer to the same network
segment as the printer.
With EpsonNet Config (Web version), you can set more items than with EpsonNet Config.
Method 3: Setup using arp/ping commands
This method involves setting the printer's IP address in the setting computer's arp/ping commands, then using
the setting tool to change the other settings.
The setting computer must be in the same segment as the printer. Also, settings can be done only when the
printer's arp+ping IP setting is set to Enable.
Use EpsonNet Config or EpsonNet Config (Web version) for settings other than the IP address.
Flow of Setup
Change network settings
on setting computer
Setup using EpsonNet
Config
Printing the status sheet (check settings) (See "Printing a Status Sheet" on page 71.)
Method 1 Method 2 Method 3
- Use EpsonNet Config to perform
other settings
- Use EpsonNet Config (Web version)
to perform other settings
Use arp/ping command to set
printer IP address
Finish Finish Finish
Use EpsonNet Config
(Web version) to perform settings

Epson TM-m30II Specifications

General

Type	POS printer
Character sets	ANK
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum roll diameter	83 mm
Supported paper width	58 mm - 80 mm (Breite) mm
Maximum printing width	80 mm
Power plug type	Type G
Power source type	AC
USB port	Yes
USB connector	USB Type-A / USB Type-B
USB 2.0 ports quantity	2
Connectivity technology	Wired
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	No
Internal memory	- MB
Built-in barcodes	-
Country of origin	Philippines
Mounting position	Horizontal/Vertical
Autocutter durability	1.5 million cuts
Built-in sensors details	Paper End Sensor, Papier-Sensor
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	360000 h
Product color	White
Print head life	150.000.000 Impulse
Mean cycles between failures (MCBF)	65000000
Pre-installed software	TMNet WebConfig, ePOS-Device, ePOS-Display, ePOS-Print
Package depth	240 mm
Package width	200 mm
Package weight	2150 g
Quantity per pack	1 pc(s)
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Master (outer) case weight	0 g
Harmonized System (HS) code	84433210
Quantity per master (outer) case	4 pc(s)

Weight and Dimensions

Width	127 mm
