EVCO S.p.A. EV3 CHIL & EVD CHIL | Installer manual ver. 1.2 | Code 1443DCHILE124
page 17 of 46
Connector 3
PART DESCRIPTION
1 Analogue output AO2 (0-10 V/phase cutting/PWM)
2 Analogue outlet AO1 (0-10 V/phase cutting/PWM)
3 Reference (GND) for analogue inputs, digital inputs, analogue outputs and powered INTRABUS port
4 Analogue input IN1 (NTC/4-20 mA)
5 Dry contact digital input IN10
6 Analogue input IN2 (NTC)
7 Dry contact digital input IN9
8 Analogue input IN3 (NTC)
9 Dry contact digital input IN8
10 Analogue input IN4 (NTC)
11 Dry contact digital input IN7
12 Digital input IN5
13 Reference (GND) for analogue inputs, digital inputs and analogue outputs
14 Dry contact digital input IN6
15 Reference (GND) for analogue inputs, digital inputs and analogue outputs
16 power supply for analogue inputs 4-20mA (12 VDC, max. 120mA)
17 Open collector digital output OC1 (12V, max. 40mA)
18 Reference (GND) for analogue inputs, digital inputs and analogue outputs
