6 LIST OF PARAMETERS
6.1 Initial information
The three levels of access to the parameters are shown in the first column of the following table with letters:
U User
S Servicer
M Manufacturer
For more information see the previous paragraph 5.4.1.
MENU PARAM. DEFAULT MIN. MAX. U.M. SET-POINT
U CooL 7.0 CF04 CF03 °C Temperature set-point
MENU PARAM. DEFAULT MIN. MAX. U.M. CONFIGURATION
S CF03 20.0 CooL 90.0 °C Maximum set-point value
S CF04 4.0 -50.0 CooL °C Minimum set-point value
S CF06 0 0 1 - - - -
Controller LED meaning
0 = cooling ON
1 = cooling ON
S CF07 1 0 1 - - - -
Enable clock
0=No
1= Yes
S CF08 1 1 200 - - - - MODBUS serial address
S CF09 1 -127 127 - - - - Servicer password
M CF10 2 -127 127 - - - - Manufacturer password
M CF11 0 0 1 - - - - Compressor parcelling number
M CF12 1 1 2 - - - - Number of compressors
M CF17 0 0 2 - - - -
IN1 input configuration type
0= Temperature [°C]
1= 4-20mA [Bar]
2= Not used
The choice of CF17 value determines the unit of
measurement for the condensation (°C or Bar)
M CF31 0,0 -50,0 80,0 Bar Start of condensation pressure scale
M CF32 50,0 -50,0 80,0 Bar Bottom of condensation pressure scale
