XT Series DISK RECORDER - Version 10.03 - Hardware

Technical Reference Manual

Issue

10.03.B

EVS Broadcast Equipment SA

–

July 2010

3 Relay Out 2 16 Relay Out 2

4 Relay Out 1 17 Relay Out 1

5 IN + opto 4 18 IN - opto 4

6 IN + opto 3 19 IN - opto 3

7 IN + opto 2 20 IN - opto 2

8 IN + opto 1 21 IN - opto 1

9 I/O TTL 8 22 GND (Return I/O 8)

10 I/O TTL 7 23 GND (Return I/O 7)

11 I/O TTL 6 24 GND (Return I/O 6)

12 I/O TTL 5 25 GND (Return I/O 5)

13 + 5V 50mA max.
