EVS XT-3 User Manual

Monitoring Limitations
The monitoring of PGM B on J3 is only possible in a 1 REC + 1 PLAY configuration.
In a 2REC + 1 PLAY configuration, the monitoring of the player 1 is only available with the
internal multiviewer.
In a 1REC + 2PLAY configuration, the monitoring of the player 2 is only available with the
internal multiviewer.
6.2.7. Channel Assignment
Server with Three Codec Boards
The following table shows how the channels (play or record channels) are assigned to the
codec boards and connectors:
Codec Board Codec Connector Channel Number
Lower codec board (slot 2) COD A CAM F or PGM 1
Lower codec board (slot 2) COD B CAM E or PGM 2
Middle codec board (slot 3) COD A CAM D or PGM 3
Middle codec board (slot 3) COD B CAM C or PGM 4
Upper codec board (slot 4) COD A CAM B or PGM 5
Upper codec board (slot 4) COD B CAM A or PGM 6
Server with Two Codec Boards
The following table shows how the channels (play or record channels) are assigned to the
codec boards and connectors:
Codec Board Codec Connector Channel Number
Lower codec board (slot 2) COD A CAM D or PGM 1
Lower codec board (slot 2) COD B CAM C or PGM 2
Middle codec board (slot 3) COD A CAM B or PGM 3
Middle codec board (slot 3) COD B CAM A or PGM 4
100 6. Boards Description
EVS Broadcast Equipment SA Issue 12.05.C- November 2014

EVS XT-3 Specifications

General

Power Supply	Dual redundant power supplies
Processor	Intel Xeon
RAID Support	RAID 0, 1, 5, 6, 10
Recording Format	ProRes, DNxHD
Control Interface	Ethernet
Network Connectivity	10Gb Ethernet
Video Format	HD
Networking	Ethernet
Memory	32GB
Storage	SSD
Operating System	Linux
Form Factor	Rackmount
