PRODUCT FUNCTIONALITY
31
Chapter7
Remove and restore the boiler power supply using the master switch or using the power supply cable.1.
The boiler sequentially displays the following items before reaching “OFF”:2.
Microprocessor version (LP_V.... or successive versions)
Mode Selection (WINTER as set in the factory)
Language (LANGUAGE)
Current day and time adjustment (CLOCK)
Level (LEVEL setting reserved for authorised technicians)
When “WINTER” appears, press button 5 to access the adjustment mode.3.
Display D1 will show the mode currently selected while display D2 will show “Mod-”: use keys 2 and 3 to 4.
select the mode from those available: WINTER – SUMMER – WINTER-DOMESTIC
Once the desired mode has been selected, press button 1 to escape and con rm.5.
WINTER MODE
The boiler works controlling both thermostats: only when both thermostats are satis ed, the boiler
switches o after a 15 minutes delay showing “TOFF” on the display.
WINTERDOMESTIC MODE
The boiler works controlling both thermostats, but in this case input INP2 has priority with respect to
INP1. When input INP2 must be satis ed the display shows DHW.
only when both thermostats are satis ed, the boiler switches o after a 15 minute delay showing “TOFF”
on the display.
SUMMER MODE
The boiler works only controlling the state of the priority input INP2, the state of the input INP1 is
completely ignored and therefore also output OUT_4 is always disabled. When the thermostat is satis ed
the boiler switches o without any delay, showing “TOFF” on the display.
Electrical features applicable external devices:
Max. voltage: 230 V
Frequency: 50 Hz
Max. power per channel: 250 W
SAFETY ZONE
This function activates if the water temperature inside the boiler exceeds 85°C: even if there is no
request for heat, the electro-thermal pump/control relating to OUT4 and OUT3 is enabled.
The stopping of the electro-thermal pump/controls will happen when the temperature decreases.
It is fundamental that the installer foresees the presence of an important heating area in the
home, in which at least one radiator is never closed.
The lack of a venting area can lead to boiler overheating with consequent activation of the
mechanical safety devices. The outputs performed by the Extra ame after-sales service in order to
release these safety devices are under the customer’s responsibility.
