Installation manual
BCSD
System
1.
GENERAL SYSTEM DIAGRAM
REF. 1711
Mains filters
1.3 Mains filters
It is recommended to insert a mains filter at each axis. These mains filters are mandatory to comply
with European regulations.
Use the noise filter Manufactured by SCHAFFNER at the brake power input for servomotors with
holding brakes.
Three-phase servo drive should carry three-phase filter. Choose the right filter according to the
items.
Power range Noise filter current
200 W - 1 kW FN258-7-33
1.5 kW - 2 kW FN258-16-33
3 kW - 5 kW FN258-30-33
In order to comply with European Directive 2014/35/EU on Low Voltage and 2014/30/EU on
Electromagnetic Compatibility, it is recommended to insert a mains filter.
