Fagor BCSD User Manual

·48·
Installation manual
BCSD
System
5.
CNC
REF. 1711
Access to the variables from the CNC
5.2 Access to the variables from the CNC
The variables will be identified at the CNC with the SERCOS number:
Read-only variables:
Write variables:
All the parameters of the drive may be read and written using the SVAR variable.
Example:
P100=SVARn SERCOS-ID where n indicates the axis. The SERCOS identifier appears on the CNC
screen for the machine parameters of the drive.
VARIABLE SERCOS-ID NAME
CV3 33079 CurrentFeedback- Amp
PV51 00051 PositionFeedback1
SV2 00040 VelocityFeedback
TV2 00084 TorqueFeedback (percentage of rated torque x10)
VARIABLE SERCOS-ID NAME
SV1 00036 VelocityCommand
