GENERAL SYSTEM DIAGRAM
1.
REF. 1711
·9·
System configurations
1.1 System configurations
The following tables show the possible system configurations; in other words, the various motors
and drives available with their corresponding cables:
Spindle motors FS5:
Low inertia 750 W servo motors:
Motor Drive Pn nmax
FS5-A037-S5C
-A SCD 1.25 3.7 kW 8000 rpm
FS5-A055-S5C
-A SCD 2.35 5.5 kW 8000 rpm
FS5-A075-S5C-A SCD 2.35 7.5 kW 8000 rpm
FS5-A110-S5C
-A SCD 2.50 11.0 kW 8000 rpm
FS5-A150-S5C
-A SCD 2.75 15.0 kW 8000 rpm
Motor Drive
FBS-08ADB12 BCSD-08AMA-01 Fagor axis motor, 200 V AC, 750 W, Absolute Encoder 131072P/R,
Flat without keys, With Oil Seal.
FBS-08ADB14 BCSD-08AMA-01 Fagor axis motor, 200 V AC, 750 W, Absolute Encoder 131072P/R,
Flat without keys, With Oil Seal, with brake (DC 24 V).
FBS-08ADB22 BCSD-08AMA-01 Fagor axis motor, 200 V AC, 750 W, Absolute Encoder 131072P/R,
Flat with keys with screw thread, With Oil Seal.
FBS-08ADB24 BCSD-08AMA-01
Fagor axis motor, 200 V AC , 750 W, Absolute Encoder 131072P/R,
Flat with keys with screw thread, With Oil Seal, with brake (DC 24 V).
Power cable
MPC-FBS-18-3 Motor Power cable for FBS 750 W/1 kW motor, 3 meter long.
MPC-FBS-18-5 Motor Power cable for FBS 750 W/1 kW motor, 5 meter long.
MPC-FBS-18-8 Motor Power cable for FBS 750 W/1 kW motor, 8 meter long.
MPC-FBS-18-10 Motor Power cable for FBS 750 W/1 kW motor, 10 meter long.
MPC-FBS-18-15 Motor Power cable for FBS 750 W/1 kW motor, 15 meter long.
MPC-FBS-18-20 Motor Power cable for FBS 750 W/1 kW motor, 20 meter long.
Encoder cable
EEC-FBS-A-3 Motor Encoder cable for FBS absolute motor, 3 meter long.
EEC-FBS-A-5 Motor Encoder cable for FBS absolute motor, 5 meter long.
EEC-FBS-A-8 Motor Encoder cable for FBS absolute motor, 8 meter long.
EEC-FBS-A-10 Motor Encoder cable for FBS absolute motor, 10 meter long.
EEC-FBS-A-15 Motor Encoder cable for FBS absolute motor, 15 meter long.
EEC-FBS-A-20 Motor Encoder cable for FBS absolute motor, 20 meter long.
