Besides the various connectors, the front panel of the drive has other
elements that are mentioned next.
Fuse
The fuse on the front panel of each modular drive is a “2.5 A (F)/250 V (fast)”
fuse and it is used to protect the internal control circuits.
Status display
The seven-segment status display shows the information on the drive status
or the corresponding code when an error or warning occurs. See section
3.3. Turning a drive on at the end of this chapter. It can also display the
transmission speed when setting it both with SERCOS-II or CAN interface.
