1.3 Stages of the system configuration
The following steps are a reference to configure and install the DDS system.
Example procedure
Stage 1. Analysis of the system location
Ambient conditions
Mechanical conditions
Electrical conditions
Cooling conditions
Stage 2. Component selection
Motors
Power supply module
Drives
Auxiliary modules
Stage 3. Connection configuration
See block diagrams
See connection diagrams
See dimension drawings
Power and signal cable selection
Suggestions for cable installation
Power line connection
Electrical cabinet and its ventilation
NOTE. This DDS system configuration process assumes that the motors
of the system are known motors.
All the motors of the FAGOR catalog are described in their corresponding
manuals:
• Manual of synchronous servo motors. FXM, FKM families.
• Asynchronous motor manuals. FM7, FM9 families.
