Fender RUMBLE STAGE 800 User Manual

64
SPECIFICATIONS
Rumble Studio 40
TYPE PR 5133
POWER REQUIREMENTS 118 watts (maximum) 45 watts (typical)
POWER AMP OUTPUT 40 watts into 8Ω
INPUT IMPEDANCE 1MΩ (instrument) 18kΩ (aux input)
EFFECTS LOOP Nominal level: -10dB Send: 220Ω (balanced) Return: 17.3kΩ (balanced)
LINE OUT OUTPUT Maximum level: +4.9dBV Impedance: 600Ω (balanced)
HEADPHONE OUTPUT 43mW/channel into 16Ω (minimum recommended impedance)
SPEAKER One 10” (25.4 cm) Special Design Ceramic 8Ω, one compression tweeter with on/off switch
FOOTSWITCH MGT-4 (optional, PN 0994071000) EXP-1 Expression Pedal (optional, PN 2301050000)
DIMENSIONS AND WEIGHT Width: 16.5” (419.1mm) Height: 16.9” (429.3mm) Depth: 12” (304.8mm) Weight: 19 lbs. (8.62kg)
Rumble Stage 800
TYPE PR 5134
POWER REQUIREMENTS 1,500 watts (maximum) 150 watts (typical)
POWER AMP OUTPUT 400 watts into 8Ω (internal) 800 watts into 4Ω/2.67Ω (with 8Ω/4Ω extension cabinet)
INPUT IMPEDANCE 1MΩ (instrument) 18kΩ (aux input)
EFFECTS LOOP Nominal level: -10dB Send: 220Ω (balanced) Return: 17.3kΩ (balanced)
LINE OUT OUTPUT Maximum level: +4.9dBV Impedance: 600Ω (balanced)
HEADPHONE OUTPUT 43mW/channel into 16Ω (minimum recommended impedance)
SPEAKERS Two 10” (25.4 cm) Eminence® Ceramic 16Ω, one compression tweeter with on/off switch
FOOTSWITCH MGT-4 (included, PN 7710238000) EXP-1 Expression Pedal (optional, PN 2301050000)
AMP COVER Optional, PN 7712953000
DIMENSIONS AND WEIGHT Width: 19” (482.6mm) Height: 23.7” (602mm) Depth: 14” (355.6m) Weight: 39 lbs. (17.7kg)
Product specifications subject to change without notice.

Fender RUMBLE STAGE 800 Specifications

General

Power Output	800 Watts
Speaker Configuration	2 x 10"
Tweeter	Compression Tweeter with On/Off Switch
Color	Black
Connectivity	Bluetooth, USB
EQ	3-band EQ
Footswitch	Optional (sold separately)
