The vacuum has two modes of operation: manual and
the connected power tool is turned on, and start and stop
automatically. The vacuum will continue to run for a couple
seconds after the tool is turned off in order to clear remain-
vacuum is turned on and off when the tool is turned on
The variable suction power can be adjusted with the
Tools with very low power consumption may
not draw enough power from the tool receptacle
to be detected by the vacuum. For variable speed
tools, it may be necessary to turn the speed up to
trigger the vacuum, and then back down for normal
Suction
Power
Tool
Receptacle
Manual
Off
Auto
Power Cord Bracket (Reel)
reel for storing the power cord on the back of the vacuum.
This gives the added feature of being able to store the
power cord either in the hose garage or on the cord reel.
Note however, that the cord reel isn’t compatible with the
optional boom arm. So if you are going to install the boom
arm, you should skip this procedure.
Using the provided screws, secure the cord bracket to the
motor housing of the vacuum, as shown.
Mounting
Holes
Mounting
Screws
To Next Page
