Transport Handle
A transport handle can be added to the CT-22 through CT-55
vacuums. The handle aids in moving the vacuum around the


Boom Arm
” on page 15).
CT-22/33/44/55 Handle Installation
1.
R
emove the motor housing from the collection canister.
2.
Carefully prop the collection canister up with the front
facing down. Mak
e sure it is stable so it doesn’t fall over
while you work.
3.
R
emove the two screws that secure the existing cord

nuts and brackets for reuse.
Cord
Brackets
Handle Lower
Mounting Holes
4.

canister
.
canister.canister
Square Nuts
5.

handle’
s lower mounting bracket. Make sure they are
inserted all the way into the deep slots.
Square Nuts
Lower Handle
Bracket

Place the handle on the collection canister slightly below


mounting holes line up with the three screw locations in
the lower support bracket.
7.
Slide the two handle br
ackets down the handle until their
mounting holes line up with the upper holes in the collec-
tion canister. (Make sure the 4 square nuts haven’t fallen
out of position.)
Mounting
Screws (3)
Lower Support
Bracket
Handle
Brackets
8.
Place the upper support br
acket over the handle
brackets.

Tighten the 3 screws on the lower support br
acket, and 4
screws on the upper support bracket.
10.


using the original 2 screws and square nuts.
Mounting
Screws (3)
Mounting
Screws (4)
Upper Support
Bracket
