FLIR A6000 Series User Manual

7 – Specifications
A6000 and A8500 Series User’s Manual 80
Max @ Min Window
480Hz@¼
4,130Hz @ 16x4
26,150Hz
@ 32x4
Minimum
<1Hz
Resolution
480nS
Pixel Rate (burst)
100 MHz
Integration Width:
Maximum
~full frame period (1/frame rate)
Minimum
480nS
Resolution
160nS
Digital Video Output:
Selectable:
• Raw digital video (14-bits)
• Gain and offset (NUC) corrected (14-bits)
• NUC with bad pixel replaced (14-bits)
7.4 HD-SDI Video
7.4.1 A858x and all A6000 models
Video Output
SD-SDI 480i, 576i
HD-SDI 720p @ 50/59.9Hz or 1080p @ 25/29.9
Data Output
Selectable
• Raw, uncorrected
• Corrected
AGC
Selectable
• DDE
• Plateau based equalization
• Linear equalization
AGC Filter
User controlled damping factor
User controlled update rate
