REAR
SEATS
Head
restraints
Lift
the
head
restraint
so
that
it
is
located
directly
or
as
close
as
possible
behind
your
head.
The
head
restraints
can
be
moved
up
and
down
by
pulling
up
on
the
head
restraint.
Push
button
to
lower
head
restraint.
Seat
mounted
cup
holders
(if
equipped)
Deploy
by
pressing
the
button
on
top
of
the
cupholder
.
2006
Freestar
(win)
Owners
Guide
(post-2002-fmt)
USA
(fus)
Seating
and
Safety
Restraints
117
116
118
