How does the Safety Canopy姟 system work?
The design and development of the
Safety Canopy娂 system included
recommended testing procedures
that were developed by a group of
automotive safety experts known as
the Side Airbag Technical Working
Group. These recommended testing
procedures help reduce the risk of
injuries related to the deployment of
side airbags (including the Safety
Canopy娂).
The front passenger sensing system
will disable the side airbag if the
seat is empty.
The Safety Canopy娂 system
consists of the following:
• An inflatable nylon curtain with a
gas generator concealed behind the headliner and above the doors
(one on each side of vehicle).
• A headliner designed to flex open above the side doors to allow Safety
Canopy娂 deployment.
• The same readiness airbag light, electronic control and diagnostic unit
as used for the front airbags.
• Two crash sensors mounted under the front seats (one on each side).
• Two crash sensors located at the c-pillar behind the rear doors (one
on each side).
• Rollover sensor in the restraints control module (RCM).
The Safety Canopy娂 system, in combination with safety belts, can help
reduce the risk of severe injuries in the event of a significant side impact
collision or rollover event.
Children 12 years old and under should always be properly restrained in
the second or third row seats. The Safety Canopy娂 will not interfere
with children restrained using a properly installed child or booster seat
because it is designed to inflate downward from the headliner above the
doors along the side window opening.
2006 Freestar (win)
Owners Guide (post-2002-fmt)
USA (fus)
Seating and Safety Restraints
165
