ENGINE DATA
Engine 3.9 L OHV V6 engine 4.2L OHV V6 engine
Cubic inches 232 256
Required fuel 87 octane 87 octane
Firing order 1-4-2-5-3-6 1-4-2-5-3-6
Ignition system EDIS EDIS
Spark plug gap 0.052–0.056 inch
(1.32–1.42mm)
0.052–0.056 inch
(1.32–1.42mm)
Compression ratio 9.36:1 9.27:1
VEHICLE DIMENSIONS
Vehicle dimensions
Wagon - inches (mm)
Van - inches (mm)
(1) Overall length 201.0 (5105) 201.0 (5105)
(2) Overall width 76.4 (1941) 76.4 (1941)
(3) Overall height 70.6 (1793)
1
68.8 (1748)
2
(4) Wheelbase 120.8 (3069) 120.8 (3069)
(5) Tread - Front 64.7 (1644) 64.7 (1644)
(5) Tread - Rear 62.8 (1595) 62.8 (1595)
1
Equipped with P225/60R16 tires.
2
Equipped with P235/60R16 tires.
2006 Freestar (win)
Owners Guide (post-2002-fmt)
USA (fus)
Maintenance and Specifications
311
