Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
75 Diode PCM
76 Diode A/C clutch
* Mini Fuse ** Cartridge Fuse
Auxiliary relay box (cooling fans)
The relay box is located in the engine compartment by the radiator.
Fuse/Relay
location
Fuse amp
rating
Description
1 — Cooling fan relay #4
2 — Cooling fan relay #5
3 — Cooling fan relay #3
4 — Cooling fan relay #1
5 — Cooling fan relay #2
6 40A* Right-hand cooling fan motor (Vehicles with
trailer tow package only)
7 15A** Low-speed cooling fan circuit breaker
(Vehicles with trailer tow package only)
8 40A* Left-hand cooling fan motor (Vehicles with
trailer tow package)
10A** Low-speed cooling fan circuit breaker
(Vehicles without trailer tow package)
* Maxi fuse **Circuit breaker
2006 Freestar (win)
Owners Guide (post-2002-fmt)
USA (fus)
