Removing and installing com ponents
during servicing
Attaching the cover
1
2
2
► Place the cover in the correct mounting position (1).
If you remove more than one compo nent at th e same time, keep the screws for the
individual components s epa rately from each other and make sure that you use the
correct screws. I f you install the wrong screws, componen ts m ay be dama ged.
► Tighten the screws (2).
► Inser t the ba
ttery (see Chapter " Inserti ng battery", Pa ge 31).
Finishing component removal
After you have removed or cha nged t he system components as you required, please
prepare your device for operation again as follows:
► Install the battery again (see "
Inserting battery", Page 31).
► Turn the
notebook the right way up again and place it on a flat surface.
► Reco nnect the cables th at you disconnecte d before.
56 Fujitsu
