Getting started
Connecting the device
Please observe the safety information in "Important notes", Page 7.
CE conformance and optimum picture quality a re guaranteed only if
you use the data cables supplied.
► Switch off the monitor and the computer.
► Disconnect the power plug
from the computer.
Connecting cables to the monitor
The data cables supplie
d have two 15-pin D-SUB connectors or two 24-pin D VI
connectors for connect
ion to the monitor and to th e computer.
Informationonthecom
puter connections and interfaces is conta ined in the
operating manual for
the computer.
2
3
45
67
1
7
1=Securi
ty slot for the "Kensington Lock"
2 = Po wer connector
3=DVI-D
socket (DVI)
4 = D-SUB socket (VGA)
5 = AUDIO-
IN socket
6 = USB IN (Downstream)
7=USBOU
T(Upstream)
► Select the appropriate data cable for your computer.
Fujitsu Technology Solutions 17
