Fujitsu B22T-7 LED proGREEN User Manual

Techn ical specification
Te chnical specification
Condensation is not permitted, neither in the rated range of operation
nor in th e limit range of operation.
B22T-7 LED
proGREEN
B24T-7 LED
proGREEN
Dimensions and weight
Visible diag onals 54.6 cm 60.97 cm
Dot pitch 0.2479 mm 0.2767 mm
Width 476.1 mm 531.4 mmImage size
Height 267.8 mm 299.0 mm
Maximum resolution 1920 x 1080 1920 x 1080
Width 516 mm 571.72 mm
Height 339.25 mm 362.63 mm
Dimensions incl.
monitor base
Depth 203.98 m m 203.98 mm
Weight (without packaging)
approx. 5.75 kg approx. 6.0 75 kg
Storable di
splay modes
40 40
Pixel erro
rclasses
accordin
gto
ISO 9241-
307
Class
II
Electri
cal data
Analog
positive, 0.7 V
ss
,75Ω positive, 0.7 V
ss
,75Ω
Video
Digital
DVI-D/HDMI with
HDCP
DVI-D/HDMI with
HDCP
Sync
hronisation
Sepa
rate S y nc. TTL,
posi
tive or negative
Sepa
rate Sync. TTL,
posi
tive or negative
Horizontal frequency
15 k
Hz .... 82 kHz
(mu
lti-scanning)
15 k
Hz .... 82 kHz
(mu
lti-scanning)
Refresh rate
49
Hz .... 76 Hz
49
Hz .... 76 Hz
Maximum pixel rate 165 MHz 165 MHz
Power supply
Switches automat ically
100V–240V,
50 Hz – 60 Hz
Switches automatically
100 V – 240 V,
50 Hz – 60 Hz
Normal operation 24 W 26 W
ECO operating mode
23 W 23 W
Typical power
consumption
(excluding audio, USB)
Power saving mode < 0.5 W < 0.5 W
Sound output 1.5 W left; 1.5 W rig ht 1.5 W left; 1.5 W right
33

Fujitsu B22T-7 LED proGREEN Specifications

General

3D	No
Panel type	TN
Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Display surface	Matt
Display diagonal	21.5 \
Display technology	LED
Vertical scan range	56 - 76 Hz
Horizontal scan range	30 - 82 kHz
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720i, 720p
Viewable size, vertical	268 mm
Viewing angle, vertical	170 °
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	476 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1366 x 768, 1440 x 900, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
On/off switch	-
Mean time between failures (MTBF)	70000 h
HDCP	Yes
USB hub version	2.0
DisplayPorts quantity	0
Headphone connectivity	3.5 mm
USB Type-A downstream ports quantity	4
RMS rated power	3 W
Number of speakers	2
Pivot angle	0 - 90 °
LED indicators	Power
Tilt angle range	-5 - 35 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, NOR, POL, POR, RUS, SWE, TUR
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.2 W
Power consumption (standby)	- W
Power consumption (typical)	22 W
Power consumption (PowerSave)	0.3 W
Certification	CE 2004/108/EEC, EN 60950, RoHS, WEEE, IT-Eco
Product color	Black
Operating temperature (T-T)	5 - 35 °C
Package weight	7000 g
Cables included	AC, Audio (3.5mm), DVI, USB, VGA
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (with stand)	200 mm
Height (with stand)	339 mm
Weight (with stand)	5800 g
Depth (without stand)	61 mm
Width (without stand)	516 mm
Height (without stand)	320 mm
Weight (without stand)	3100 g
