Your LCD screen ...
Your LCD screen...
has a whole range of useful f eatures and functions, e.g.:
• TFT d isplay (Thin Film Transistor; active ma trix)
• minimal space requirement
s thanks to slim casing
• optimum ergonomic cha racteristics (totally distortion-free, excellent picture
definition and colour purity right into th e corners)
• high degree of brightne
ss and good co ntrast
• high resolution (1920 x 1080)
• presentation of up to 1
6.7 million colours (in conjunctio n with an appropriate display adapter)
• automatic scanning of horizontal f requen cies from 30 to 82 kH z and refresh rates
(vertical frequencies) from 56 to 76 Hz (absolutely flicker-free)
• Digital screen contr
oller with m icrop rocessor for storing 40 different display modes
• freely adjustable colour alignment for matching the screen colours to the
colours of various input and output devices
• convenient opera
tion via integrated OSD (On-Screen-display) menu
• VESA-DDC compatibility
• VESA-FPMPMI com
patibility (Flat Panel Monitor Physical Mounting Interface) –
Mounting device
for swive l arm or a similar accessory
• Plug&Play capability
• Digital video
inputs (DVI and HDMI) with HDCP
• power management for reducing power consumption when th e computer is not in use
• Compliance w
ith the recommendations according to T CO 6.0
• the mo nitor fulfills all GS ("Geprüfte Sicherheit", Certified Security) requireme nts.
This operat
ing manual contains important information you require to start up and run your LCD monitor.
A graphics c
ard (display adapter) with VGA interface or a digital display adapter with DVI interface
or video si
gnal source with HD MI interface is required to control the LCD monitor. The monitor
processes
the data supplied to it b y th e d isplay adap ter. The disp lay adapter or the associated
driver so
ftware is responsible for setting the modes (reso lution and refresh rat e).
When putt
ing the monitor into operation for the first time, the screen display should b e
optimal
ly adapted to the display adapter used and adjusted in accordance with your
needs (s
ee chapter "
Changing the monitor settings", Page 21.
Target group
You don’t need to be an "expert" to pe rform the operations de scribed here.
Nonetheless, it is important to always obse rve the s afety notes given in the operating
instructions for the computer and in this man ual.
In th e even t of any pro blems, please contact your sales office or our Service Desk.
5

Fujitsu B22T-7 LED proGREEN Specifications

General

3D	No
Panel type	TN
Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Display surface	Matt
Display diagonal	21.5 \
Display technology	LED
Vertical scan range	56 - 76 Hz
Horizontal scan range	30 - 82 kHz
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720i, 720p
Viewable size, vertical	268 mm
Viewing angle, vertical	170 °
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	476 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1366 x 768, 1440 x 900, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
On/off switch	-
Mean time between failures (MTBF)	70000 h
HDCP	Yes
USB hub version	2.0
DisplayPorts quantity	0
Headphone connectivity	3.5 mm
USB Type-A downstream ports quantity	4
RMS rated power	3 W
Number of speakers	2
Pivot angle	0 - 90 °
LED indicators	Power
Tilt angle range	-5 - 35 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, NOR, POL, POR, RUS, SWE, TUR
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.2 W
Power consumption (standby)	- W
Power consumption (typical)	22 W
Power consumption (PowerSave)	0.3 W
Certification	CE 2004/108/EEC, EN 60950, RoHS, WEEE, IT-Eco
Product color	Black
Operating temperature (T-T)	5 - 35 °C
Package weight	7000 g
Cables included	AC, Audio (3.5mm), DVI, USB, VGA
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (with stand)	200 mm
Height (with stand)	339 mm
Weight (with stand)	5800 g
Depth (without stand)	61 mm
Width (without stand)	516 mm
Height (without stand)	320 mm
Weight (without stand)	3100 g
