ErgoPro m664 PC Specialist's Handbook
Page 6-8 Edition 1 - Release 1 - March 1998
Add-on board slots on system board
The system board in ErgoPro m664-series has the following slots:
· 1 AGP slot (32-bit)
· 3 PCI slots (32-bit)
· 1 shared PCI/ISA slot (32-bit/16-bit)
· 1 ISA slot (16-bit)
All PCI slots are master slots.
Front panel indicators
The front panel has two indicators (LEDs), from top to bottom:
Power (Green/Orange) Illuminated (green) when the system is ON, orange in Power Save mode.
HDD (Orange) Illuminated during HDD activity.
