External device connection
153
❖
Removing USB mass storage
･
Do not remove USB mass storage while transferring data.
Doing so may damage the data.
1
From the Home screen,
→
[Settings]
→
[Storage]
2
[Unmount USB storage]
→
Remove USB cable
◆
Displaying on a TV via MHL connection
Connect the terminal to a TV with HDMI/MHL connectors to
display videos or images on the TV.
･
To connect to an MHL-TV, an MHL cable (commercially
available) is required.
･
To connect a TV equipped with HDMI terminal, the following
cables are required.
- HDMI standard certified HDMI cable (Category 2)
compatible with HDMI plug (Type A) (commercially
available)
- HDMI conversion cable L01 (optional) or HDMI conversion
cable SC01 (optional)
･
For HDMI conversion cable, connection with microUSB
cable (optional) or AC Adapter 04 (optional) is required. For
details on connection, refer to the HDMI conversion cable
manual.
･
DOCOMO does not guarantee actual operations for all HDMI
devices.
1
Connect an HDMI cable with an HDMI
conversion cable
･
For details on connection of HDMI conversion cable,
refer to the HDMI conversion cable manual.
2
Connect the HDMI cable to a TV HDMI port
･
For HDMI connection, switching input, volume control,
etc, refer to the operation manual of the TV.
3
Connect the HDMI conversion cable to the
external connection jack of the terminal
･
If the HDMI cable is unplugged while displaying on the
TV, the terminal turns to connection stand-by mode for
a certain period of time.
✔
INFORMATION
･
When connecting the TV that does not support HDCP, images
or sounds are not output properly.
･
When starting MHL output, the TV input mode may not
switch and images may not be displayed depending on the
TV connected. In that case, switch input mode using a TV
remote control etc.
･
The output data from the terminal may not fit the TV screen
depending on the TV connected. In that case, change the TV
display setting.
･
While the HDMI cable is connected, do not hold the HDMI
cable to lift the terminal.
･
Remove the HDMI cable when not displaying on the TV.
･
Radio wave conditions may be affected depending on your
usage environment when using MHL connection.
To Next Page
