Fujitsu ScanSnap S510M Getting Started Guide

33
Chapter 6 Consumables
This chapter describes how to replace and purchase consumables and regular replacement parts.
6.1 Part Numbers and Replacement Cycle of Consumables
The following table lists the part numbers of consumables and shows rough guidelines for replacing these
parts.
These replacement cycles are rough guidelines when A4/Letter wood-free paper 80g/m
2
(21 lb) is used.
The actual cycle may differ depending on the scanned paper.
Use only the consumables specified by PFU LIMITED.
WARNING
• Before you replace the consumables of the ScanSnap, unplug the power cable from the
power outlet to prevent from fire or electric shock.
• To avoid injuries, do not place the internal parts (such as the Pad ASSY and pick roller)
in areas where small children can reach.
No Description P/N Replacement Cycle
1 Pick roller PA03360-0001 100,000 sheets or one year
2 Pad ASSY PA03360-0002 50,000 sheets or one year
HINT
Use the following procedure to check the target values for
replacement and usage information of consumables.
1. Click and hold the ScanSnap Manager icon in the Dock
menu.
2. Click [Check consumable supplies] on the menu.
⇒
The "ScanSnap Manager - Check consumable
status" window appears. This window indicates
how many times consumables have been used.
Replace consumables using "Target value to change supplies" as guidelines.
For details about purchasing consumables, visit the website below or contact the FUJITSU
scanner dealer where you purchased your ScanSnap.
[Website] http://scansnap.fujitsu.com/
For information on how to replace the Pad ASSY and the pick roller, refer to "9.2 Replacing
the Pad ASSY" and "9.3 Replacing the Pick Roller" respectively in the "ScanSnap
S510M Operator’s Guide."
