1.34 Color Schemes
1.34.1 Preset color schemes
Preset color schemes are provided for optimum viewing in daytime, nighttime and twilight. Below
are the default color settings for each preset color scheme.
1. Press the MENU key to show the menu.
2. Choose Brill/Color and press the ENTER key.
3. Choose Display Color and press the ENTER key.
4. Choose a color scheme and press the ENTER key.
5. Press the MENU key to close the menu.
1.34.2 User color scheme
The user color scheme lets you choose desired echo color and background color. The display
color must be set for “User” (see paragraph 1.34.1) to use user chosen echo and background
colors.
1. Press the MENU key to show the menu.
2. Choose Brill/Color and press the ENTER key.
3. Choose Echo Color and press the ENTER key.
4. Choose appropriate option and press the ENTER key. “Multi” displays echoes in colors of red,
yellow and green according to echo strength, and it is not available in the IEC mode.
5. Choose Background Color and press the ENTER key.
6. Choose background color desired and press the ENTER key.
7. Press the MENU key to close the menu.
Display item, color scheme and color
DIsplay item Day Night Twilight User
Text Black Red Green Green
Range rings Green Red Green Green
Echo Yellow Green Green Yellow
Background White Black Blue Black
Day
Night
Twilight
User
Yellow
Green
Multi
Black/Green
Black/Red
Blue/White
DK Blue/White
White/Green
