Appendix A: System Configuration Worksheets 54
Appendix A:
System
Configuration
Worksheets
Customer Name _________________________________ Address
_______________________________________
City _________________ County ___________ State ___ Zip __________
Phone (____) _______________
Note
For UL listed systems, the difference between the standby current draw and the maximum cur-
rent draw of each device must be subtracted from the UL allowed alarm load of 650 mA (panel
terminal 7
—OUT1/+12)
Table A1: System Hardwire Devices
Part No. Description Qty. Standby Current Draw
Standby
Current
Subtotal
Maximum
Current Draw
Maximum
Current
Subtotal
Hardwire Sensors/Detectors
N/A System sensor models 2100D,
2100TD, 2100S, 2100TS, 2400,
2400TH, or ESL series 429AT,
521B, 521BXT
na 1.2 mA for 10 detectors Panel limited to
100 mA
13-463 Visus LP60 PIR Motion Detector 10 mA 10 mA
13-464 DS940 PIR Motion Detector 17 mA 17 mA
13-468 Optex RX-040 (PI) PIR Motion
Detector
17 mA 17 mA
SuperBus 2000 Devices (4 maximum)
60-746-01 SuperBus 2000 2x16 LCD
Alphanumeric Touchpad
57 mA 90 mA
60-820 SuperBus 2000 Fixed Display
Touchpad
33 mA 65 mA
60-803-04 SuperBus 2000 2x20 LCD
Alphanumeric Touchpad
75 mA 120 mA
60-804-04 SuperBus 2000 2x20 VFD
Alphanumeric Touchpad
75 mA 120 mA
60-774 SuperBus 2000 Hardwire Input
Module
18 mA 18 mA
SnapCards (1 per panel)
60-756 4 Input/2 Output SnapCard 10 mA
+ 2.5 mA per zone used
+ 7 mA per smoke loop used
+ 34 mA per relay used
185 mA
60-757 8Z Hardwire Input SnapCard 10 mA
+ 2.5 mA per zone used
+ 7 mA per smoke loop used
230 mA
60-758 4 Output SnapCard 6 mA
+ 34 mA per relay used
130 mA
Total Standby Current Draw (must not exceed 90 mA for UL systems)
Total Maximum Current Draw (must not exceed 750 mA)
