Special Installation Requirements 2
• Hardwire Smoke Detector:
System Sensor models 2100D, 2100TD, 2100S, 2100TS, 2400, or 2400TH learned into Sen-
sor Group 26 Sentrol (ESL) models 429AT, 521B, or 521BXT learned into sensor group 26
• Wireless Smoke Sensor 60-506-319.5 or 60-645-95 learned into sensor group 26
• IMMEDIATE TROUBLE BEEPS set to on
• UL 98 OPTIONS set to on
• RECEIVER FAILURE set to on
• SIREN VERIFY set to on
• RF TX TIMEOUT set to 4 hours
• ALARM VERIFY set to off
• DISABLE TROUBLE BEEPS set to off
UL 1023 & 985 24-Hour Backup
• For 24-hour backup, the total current draw for all connected devices is limited to 90 mA con-
tinuous using a 4.0 AH battery.
SIA System Requirements
Note
UL requirements take prior-
ity over SIA requirements.
SIA system requirements are the same as those described for a UL Listed Basic System on page
1, plus:
• If multiple annunciation is required, use Hardwire Siren part no.13-046.
SIA Setting Requirements
The following table describes programming requirements to meet ANSI-SIA CP-01.
The following table describes non-programmable (hard coded) system operation as required to
meet ANSI-SIA CP-01 and is provided only for your reference.
Shortcut
#
Function Programming
Page Reference
Testing Page
Reference
Default
Setting
Required Setting
0003 SIA False Alarm
Reduction
21 46 On On
0013 Exit Extension 22 46 On On
0014 Auto Stay Arming 22 46 On On
0016 Duress Code 23 46 Disabled Disabled
02005 Dialer Abort 28 46 On On
02006 Dialer Abort Delay 28 46 30 Sec. 15-45 sec.
02007 Cancel Message 28 46 On On
02009 Call Wait Cancel 28 46 Disabled On if reporting to central station and
customer has call waiting service
0310 Entry Delay 31 46 30 sec. 30-240 sec.
0311 Exit Delay 31 46 60 sec. 45-184 sec.
05014 Swinger Limit 35 46 1 1
0900 Smoke Verify 42 46 Off On if smoke alarms are programmed
into system
N/A Cross Zoning 57 46 Disabled Enabled for zones with a high
probability of false alarms
Function Operation
Disarm During Entry Delay Enter Code Only (or 1 + CODE)
Cancel Alarm Enter Code Only (or 1 + CODE)
Abort Annunciation Enabled
