9-6 Section 9-5 - LCD Assy
103
5147731
Inverter Assy for LOGIQ e R4.x.x / Vivid e R4.x.x / LOGIQ i R4.x.x /
LOGIQ i R5.x.x
5147731-2 1 1 x x x x
103A
5147731-2
Inverter Assy LOGIQ e R5.0.x / LOGIQ e R5.2.x/LOGIQ e R6.x.x /
LOGIQ e Vet / Vivid e R5.x.x / Vivid e R6.x.x
1 1 x x x
104
5251801
LCD panel for LOGIQ e R5.0.x / LOGIQ e R5.2.x/LOGIQ e R6.x.x /
LOGIQ e Vet/Vivid e R4.x.x / Vivid e R5.x.x / Vivid e R6.x.x / LOGIQ
i R5.x.x
5439794 1 2 x x x x
5146747 LCD panel for LOGIQ e R4.x.x /Vivid e R4.x.x / LOGIQ i R4.x.x 5439794 1 2 x x x
105
5125944-3 LCD cable 5125944-4 1 2 x x x x
105A
5125944-4 LCD Cable with JAE connector 1 2 x x x x
5125944-6
6 bits LCD cable for Service LOGIQ e R6.x.x /LOGIQ e R7.x.x /
LOGIQ e Vet/Vivid e R6.x.x
1 2 x x x
106
5184890
Cable Kit (LCD cable, KBD cables) for LOGIQ e R4.x.x / Vivid e
R4.x.x
5184890-2 1 2 x x
106A
5184890-2
Cable Kit (LCD cable, KBD cables) for LOGIQ e R4.x.x / LOGIQ i
R5.x.x
12x x
107
5244561 Hg label for Vivid e R4.x.x 1 2 x
108
5366398 LCD Cable Kit (LCD Cable and LCD Cable with JAE connector 1 2 x x x x
109
5439794
LCD Assy with Patch CD kits for LOGIQ e and LOGIQ e Vet 1
2 x x
Table 9-3 LCD Assy
Item
Part
Number
Part Name
Replaced
By
Quantity
FRU
LOGIQ e
LOGIQ e Vet
LOGIQ i
Vivid e
To Next Page
