Direction 5370626-100, Revision 18 LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid e Basic Service Manual
Chapter 3 System Setup 3-13
3-6-1-2 Physical Dimensions and weight with new LCD
The physical dimensions of the LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid e console with new LCD are
summarized in Figure 3-10 on page 3-13 .
Table 3-5 Physical Dimensions of LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid e with new LCD
Height Width Depth Unit
Console
Only
Console
with handle
Console
Only
Console
with handle
Console Only
Console with
handle
Unit
70 100 346 372 295 340 mm
2.8 3.9 13.6 14.6 11.6 13.4 inches
Figure 3-10 Overall Dimensions and weight with new LCD
WEIGHT: 5.2 KG
NOTE: Length is in mm
