1–8 489 GENERATOR MANAGEMENT RELAY – INSTRUCTION MANUAL
CHAPTER 1: GETTING STARTED
îš„ ACTUAL VALUES [Z]
Press the MESSAGE or ENTER key
îš„
ACTUAL VALUES [Z]
A1 STATUS
Press the MESSAGE key
îš„
ACTUAL VALUES [Z]
A2 METERING DATA
Press the MESSAGE key
îš„
ACTUAL VALUES [Z]
A3 LEARNED DATA
MESSAGE
îš„
PARAMETER [Z]
AVERAGES
MESSAGE
AVERAGE GENERATOR
LOAD: 100% FLA
MESSAGE
AVERAGE NEG. SEQ.
CURRENT: 0% FLA
