14–6 MULTILINK ML2400 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL
QUALITY OF SERVICE CHAPTER 14: QUALITY OF SERVICE
14.2.2 Example
The following example shows how to configure QoS.
Example 14-1: Configuring QoS
ML2400#
show port
Keys: E = Enable D = Disable
H = Half Duplex F = Full Duplex
M = Multiple VLAN's NA = Not Applicable
LI = Listening LE = Learning
F = Forwarding B = Blocking
Port Name Control Dplx Media Link Speed Part Auto VlanID GVRP STP
-------------------------------------------------------------------------------
9B1 E H 10TxUP10 NoE 1 - -
10 B2 E H 10Tx DOWN 10 No E 1 - -
11 JohnDoe E H 10Tx DOWN 10 No E 1 - -
12 JaneDoe E H 10Tx DOWN 10 No E 1 - -
13 B5 E F 100Tx UP 100 No E 1 - -
14 B6 E H 10Tx DOWN 10 No E 1 - -
15 B7 E H 10Tx DOWN 10 No E 1 - -
16 B8 E H 10Tx DOWN 10 No E 1 - -
ML2400## qos
ML2400(qos)##
setqos type=port port=10 priority=high
ML2400(qos)##
Successfully set QOS.
ML2400(qos)## show qos
==============================
PORT | QOS | STATUS
==============================
9 | None | UP
10 | Port | DOWN
11 | None | DOWN
12 | None | DOWN
13 | None | UP
14 | None | DOWN
15 | None | DOWN
16 | None | DOWN
ML2400(qos)## show qos type=port
================================
PORT | PRIORITY | STATUS
================================
9 | Low | UP
10 | High | DOWN
11 | Low | DOWN
12 | Low | DOWN
13 | Low | UP
14 | Low | DOWN
15 | Low | DOWN
16 | Low | DOWN
ML2400(qos)## setqos port=11 priority=high type=tag tag=6
Successfully set QOS.
(continued on next page)
All traffic on port 11 is sent to the
high priority queue and the QoS
tag is set to 6.
All traffic on port 10 is sent to the
high priority queue.
