15–10 MULTILINK ML2400 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL

IGMP CHAPTER 15: IGMP

Configuring IGMP (continued)

ML2400(igmp)##

show igmp

IGMP State : Enabled

ImmediateLeave : Disabled

Querier : Disabled

Querier Interval : 127

Querier Response Interval : 11

Multicasting Unknown Streams : Enabled

ML2400(igmp)## mcast disable

MCAST is disabled

ML2400(igmp)## show igmp

IGMP State : Enabled

ImmediateLeave : Disabled

Querier : Disabled

Querier Interval : 127

Querier Response Interval : 11

Multicasting Unknown Streams : Disabled

ML2400(igmp)## mcast enable

MCAST is enabled

ML2400(igmp)## show igmp

IGMP State : Enabled

ImmediateLeave : Disabled

Querier : Disabled

Querier Interval : 127

Querier Response Interval : 11

Multicasting Unknown Streams : Enabled
