NX-6V2 Control 11
IX. LOADING FACTORY DEFAULTS
To load the factory defaults, enter the program mode using the procedure on page 8, then type [9]-[1]-[0]-[#]. The keypad will beep 3
times indicating that the loading is in progress. The loading takes about 6 seconds.
X. ENROLLING MODULES AND KEYPADS
For supervision purposes, the NX-6V2 has the ability to automatically find and store in its memory, the presence of all keypads, zone
expanders, wireless receivers, and any other module connected to the data terminal. This allows these modules to be supervised by
the control panel. To enroll the modules, enter the Program Mode of the NX-6V2 control panel as described on page 8. When the
Program Mode is exited, the NX-6V2 control will automatically enroll the devices. The enrolling process takes about 12 seconds, during
which time the "Service" LED will illuminate. User codes will not be accepted during the enrolling process. If a speaker is attached to
the NX-6V2, it will click at this time. If a siren or bell is attached to the NX-6V2, it will sound for about 1 second. Once a module is
enrolled, if it is not detected by the control, the "Service" LED will illuminate.
XI. L QUICK START INSTALLATION
For most routine installations, the "Quick Start" option will allow for enabling a majority of the options available with the NX-6V2, when
communicating in Contact ID or SIA formats and without partitioning. The "Quick Start" locations can be identified by the
L symbol.
XII. PROGRAMMING LOCATIONS
LOCATION DESCRIPTION SEGMENTS....DATA TYPE
L 0 PHONE NUMBER 1 20........... numerical
The first telephone number is programmed in location 0. A "14" indicates the end of the phone number. Delays of four seconds can be
programmed at any point in the phone number by programming a "13" in the appropriate segment. If tone dialing is desired, program a
"15" in the segment where tone dialing should begin. If the entire number should be tone dialing, program a "15" in the first segment.
Program an A11" for a Ar@, and a A12" for a A#@. Caution: A call-waiting cancel on a non- call waiting line will prevent successful
connection to the central station.
L 1 ACCOUNT CODE FOR PHONE 1 6............. numerical
The account code sent when Phone 1 is dialed is programmed in location 1. Program a A10" in the segment immediately after the last
digit of the account code. If the account code is 6 digits long, program all 6 segments.
L 2 COMMUNICATOR FORMAT FOR PHONE 1 1............. numerical
Location 2 contains the communicator format used to transmit to the receiver connected to Phone 1. Consult the instructions for your
central station receiver to determine which format is compatible. Select a format from Table XII-1 COMMUNICATOR FORMAT
SELECTIONS. If you require a format other than those listed, review the override options described in location 18, to build the
appropriate format. A "15" must be programmed in location 2 in addition to the entries in location 18 in order to create a special format.
If this location contains a "0", the built-in communicator will be disabled, and the NX-6V2 will function as a local only control.
Table XII-1 COMMUNICATOR FORMAT SELECTIONS
DATA FORMAT DESCRIPTION
0 Local Communicator is disabled
1 Universal 4+2 Two digit event code 1800hz transmit 2300hz handshake double round parity 40pps
2 3+1 fast (or 4+1) One digit event code 1900Hz transmit 1400Hz handshake double round parity 20pps
3 Reserved Reserved
4 Pager 2 digit event code DTMF transmission
5 3/1 or 4/1 slow 1800hz transmit 2300hz handshake double round parity 20 p.p.s. hex capability
6 3/1 or 4/1 slow 1800hz transmit 1400hz handshake double round parity 20 p.p.s. hex capability
7 3/1 or 4/1 fast 1800hz transmit 2300hz handshake double round parity 40 p.p.s. hex capability
8 3/1 or 4/1 fast 1800hz transmit 1400hz handshake double round parity 40 p.p.s. hex capability
9 3/1 or 4/1 fast with parity 1800hz transmit 2300hz handshake single round w/parity 40 p.p.s. hex capability
10 3/1 or 4/1 fast with parity 1800hz transmit 1400hz handshake single round w/parity 40 p.p.s. hex capability
11 4+2 express 2 digit event code DTMF transmission
12 4+2 fast Two-digit event code 1900hz transmit 1400hz handshake double round parity 20 p.p.s.
13 Ademco Contact ID DTMF (see pages 43 & 44)
14 SIA FSK (see pages 43 & 44 )
15 Custom format (See location 18, page 15)
