7 Technical data

7.1 Medium

Working medium: Corrosive, inert, gaseous and liquid media which have no negative impact on the physical and

chemical properties of the body and seal material.

Control medium: Inert gases

Max. permissible viscos-

ity:

600 mm²/s (cSt)

Other versions for lower/higher temperatures and higher viscosities on request.

7.2 Temperature

Media temperature: -10 — 180 °C

for special function G: -10 – 60 °C

with special function S: -10 – 60 °C

Ambient temperature: -10 — 60 °C

Control medium temper-

ature:

0 — 60 °C

Storage temperature: -30 — 60 °C

7.3 Pressure

Operating pressure: Control function 1 (NC) - Flow direction under the seat

Actuator ver-

sion code

0G1 1G1 2G1 3G1 4G1 5G1

6 10.0 - - - - -

8 10.0 10.0 - - - -

10 10.0 10.0 22.0 - - -

15 10.0 10.0 22.0 - - -

20 - 6.0 12.0 25.0 - -

25 - 3.5 7.0 16.0 25.0 -

32 - - 4.0 10.0 18.0 25.0

40 - - 2.5 6.0 12.0 20.0

50 - - - 3.0 7.0 15.0

65 - - - - - 10.0

80 - - - - - 7.0

All pressures are gauge pressures. When the flow is over the seat (M), there may be the danger of water ham-

mer with liquid media! For max. operating pressures the pressure/temperature correlation must be observed.

GEMÜ 550www.gemu-group.com 11 / 46
