GEM 550 User Manual

7.5 Mechanical data
Weight: Actuator
DN Actuator size
0 1 2 3 4 5
6 0.24 - - - - -
8 0.24 0.62 0.90 - - -
10 0.24 0.62 0.90 - - -
15 0.24 0.66 0.97 - - -
20 - 0.73 1.00 1.70 - -
25 - - 1.10 1.80 3.20 -
32 - - 1.30 2.00 3.40 6.50
40 - - 1.60 2.10 3.50 6.60
50 - - - 2.30 3.70 6.80
65 - - - - - 7.40
80 - - - - - 8.10
Weights in kg
Body
DN Spigot
K514
Threaded
socket
Threaded
spigot
Flange
K514
Clamp
Connection types code
0, 16, 17, 37, 59,
60, 63, 65
1 9 10, 13, 47 80, 82, 86, 88
6 0.12 - 0.14 - -
8 0.12 0.25 0.12 - -
10 0.12 0.25 0.14 - -
15 0.16 0.25 0.14 - -
10 0.25 0.25 - - -
15 0.24 0.35 0.31 1.80 0.37
20 0.50 0.35 0.50 2.50 0.63
25 0.50 0.35 0.65 3.10 0.63
32 0.90 0.75 1.00 4.60 1.08
40 1.10 0.98 1.30 5.10 1.28
50 1.80 1.70 1.80 7.20 2.07
65 3.40 3.20 3.40 - 3.69
80 4.20 4.10 4.40 - 4.60
Weights in kg
