6 Order data
The order data provide an overview of standard configurations.
Please check the availability before ordering. Other configurations available on request.
Order codes
1 Type Code
Angle seat globe valve, pneumatically operated,
stainless steel piston actuator
550
2 DN Code
DN 6 6
DN 8 8
DN 10 10
DN 15 15
DN 20 20
DN 25 25
DN 32 32
DN 40 40
DN 50 50
DN 65 65
DN 80 80
3 Body configuration Code
2/2-way body D
Angle valve body E
4 Connection type Code
Spigot
Spigot DIN 0
Spigot EN 10357 series B,
formerly DIN 11850 series 1
16
Spigot EN 10357 series A (formerly DIN 11850 series
2)/DIN 11866 series A
17
Spigot SMS 3008 37
Spigot ASME BPE 59
Spigot ISO 1127/EN 10357 series C/DIN 11866 series B 60
Spigot ANSI/ASME B36.19M schedule 10s 63
Spigot ANSI/ASME B36.19M schedule 40s 65
Threaded connection
Threaded socket DIN ISO 228 1
Threaded socket Rc ISO 7-1,
EN 10226-1, JIS B 0203, BS 21,
end-to-end dimension ETE DIN 3202-4 series M8
3C
Threaded socket NPT,
end-to-end dimension ETE DIN 3202-4 series M8
3D
Threaded spigot DIN ISO 228 9
Flange
Flange EN 1092, PN 25, form B,
face-to-face dimension FTF EN 558 series 1, ISO 5752,
basic series 1
10
Flange EN 1092, PN 25, form B 13
Flange ANSI Class 150 RF 47
Clamp
Clamp ASME BPE,
face-to-face dimension FTF ASME BPE
80
4 Connection type Code
Clamp DIN 32676 series B,
face-to-face dimension FTF EN 558 series 1
82
Clamp DIN 32676 series A,
face-to-face dimension FTF EN 558 series 1
86
Clamp ASME BPE,
face-to-face dimension FTF EN 558 series 1
88
5 Valve body material Code
1.4435, investment casting 34
1.4408, investment casting 37
1.4435 (F316L), forged body 40
1.4435, investment casting C2
Note: A surface finish from the order code table "K
number" must be specified for valve body material C2.
6 Seat seal Code
PTFE 5
PTFE, glass fibre reinforced 5G
PTFE
FDA-compliant, USP class VI
5P
7 Control function Code
Normally closed (NC) 1
Normally open (NO) 2
Double acting (DA) 3
8 Actuator version Code
Actuator size 0G1 0G1
Actuator size 0M1 0M1
Actuator size 1G1 1G1
Actuator size 1M1 1M1
Actuator size 2G1 2G1
Actuator size 2M1 2M1
Actuator size 3G1 3G1
Actuator size 3M1 3M1
Actuator size 4G1 4G1
Actuator size 5G1 5G1
9 Type of design Code
Without
For higher operating temperatures 2023
Special vent system integrated in actuator 6996
Ra ≤ 0.6 μm (25 μinch) for media wetted surfaces,
in accordance with ASME BPE SF2 + SF3
mechanically polished internal
1903
Ra ≤ 0.8 µm (30 µinch) for media wetted surfaces,
in accordance with DIN 11866 H3,
mechanically polished internal
1904
Ra ≤ 0.4 μm (15 μinch) for media wetted surfaces,
in accordance with DIN 11866 H4, ASME BPE SF1
mechanically polished internal
1909
6 Order data
www.gemu-group.com 9 / 46 GEMÜ 550
