Gemini CDJ-700 User Manual

c d j - 7 0 0 m a n u a l • g e m i n i d j . c o m
16
The CDJ-700’s LCD display also has touch functionality.
The following features can used by touching the LCD
TOUCH DISPLAY (15)
TIME PROGRESS BAR Touching the TIME PROGRESS
BAR will skip to the selected position of the track.
TIME Toggles between time elapsed and time remain
display modes.
BPM Displays current BPM value in auto and manual
BPM mode or displays the BPM information from the ID3
tag when BPM mode is set to ID3.
TEMPO/PITCH Has the same functionality as MASTER
TEMPO button (page 10). When MASTER TEMPO is OFF,
PITCH is displayed in this field. When MASTER TEMPO is
ON, TEMPO is displayed in this field .
RANGE Has the same functionality as RANGE button
(page 10).
PITCH/MT VALUE Allows you to enable/disable PITCH/
MT (page 10). Additionally it shows current PITCH/MT
value.
TRACK TITLE Allows you to select title/artist/album/
genre text displaying. Touch on this area will switch be-
tween display modes.
EFFECTS PARAMETER BAR Allows you to set effect
values by touching the desired position.
TRACK WAVEFORM Displays a visual representation the
loaded track’s audio. Pressing the waveform changes the
magnification. The values are: 3.2 seconds, 6.5 seconds,
12 seconds, and 25 seconds.
TRACK SELECT Allows you to select a track or enter a
folder. Touching this area will enter a folder.
ADJUSTING CONTRAST
Pressing and holding the ENCODER (17) and ro-
tating the rotary will adjust the contrast of the
240x320 display. To increase the contrast ratio,
rotate clockwise. To decrease the contrast ratio rotate
the counter-clockwise.
TRACK TEXT DISPLAY MODE
Press the TEXT MODE / TOUCH ON/OFF (12)
to alter the displayed information on the LCD
TOUCH DISPLAY (15) between title/artist/
album/genre info for files.
PRESS and HOLD the TEXT MODE / TOUCH ON/OFF
(12) to enable/disable touch screen functionality.
TIME ELAPSED/REMAIN DISPLAY
Press and hold the TIME/AUTOCUE (11) button to
switch track time display modes between time
elapsed and time remain.
d i s p l a y c o n t r o l s
d i s p l a y o p t i o n s
l c d t o u c h s c r e e n f u n c t i o n s
1
1
2
2
3
3
4
4
9
9
5
5
6
6
7
7
8
8
10
10

Gemini CDJ-700 Specifications

General

MIDI	24 bit
Sample rate	192 kHz
Mixer section	No
Product color	Black
Frequency range	20 - 20000 Hz
Disc types supported	CD, CD-R, CD-ROM
Built-in optical drive	Yes
Audio formats supported	MP3
Signal-to-Noise Ratio (SNR)	100 dB
Number of scratcher platters	1
Display type	TFT
USB version	2.0
USB connector type	USB Type-B
Apple docking compatibility	Not supported
Input voltage	100 - 240 V
Power supply type	AC
Cables included	AC, USB

Weight and Dimensions

Depth	305 mm
Width	337 mm
Height	103.5 mm
Weight	3900 g
