Gendex Dental Systems
B-17
ORALIX AC SYSTEM INSTALLATION
3. MOBILE SYSTEM MOUNTING
The Mobile 2UDOL[$&DQGVtand incorporate SURYLVLRQVIRUWKHDWWDFKPHQWDQGVWUDLQ UHOLHIRIDILHOGLQVWDOOHG
mains FDEOHDVVHPEO\31SURYLGHGZLWKXQLW7KHDVVHPEO\FRQVLVWVRIDFRQGXFWRUKDUPRQL]HG
+99)FDEOHSROHVDQGHDUWKZLUHVL]HPP
PORQJDQGPDOHSOXJ&(($9
3.1. ROOM PREPARATION
A mating wall socket shall be prepared within 1.5 m from the chair, with the protective earth pin connected to
the equipotential earth point of the room, and with the line wires of the proper size.
NOTE
The mains resistance, with 230 V A.C. mains, as measured at the wall socket must be
less than 0.618 Ohms.
3.2. UNPACKING
Unpack each box and check the completeness according to ITEMS SUPPLIED BZ-3.
Verify also that the rated voltage of the Timer and Tubehead, as stated on the type number plates, are
corresponding to the local situation.
