E-3Gendex Dental Systems
ORALIX AC SYSTEMPREVENTIVE MAINTENANCE
4. PREVENTIVE MAINTENANCE INSTRUCTIONS
WARNING
Always disconnect the equipment from the mains supply before starting any maintenance
action: the mains voltage may be present on parts of the system (such as electronic
board, Tubehead, Folding Arm cable) even in the stand-by condition.
Do not allow liquid, spray or vapour the equipment, as they may cause short circuits or
corrosion. Use white grease Molikote Longterm W2 for any lubrication required.
In case of replacement/maintenance of Tubehead, Folding Arm and Extension Arm it is
necessary to park the Folding Arm in a safe position by guiding the arm slowly to the
horizontal position opposing by hand to the springs action directed upwards (see figure in
pag.B14).
If the Folding Arm is released without Tubehead and without opposing by hand to the
springs action, it is possible to damage the springs themselves.
4.1. VISUAL INSPECTION
4.1.1. Cables, connectors and plugs
Verify that all cables are not damaged and properly fixed: that no conductor lead is exposed or stressed.
Connectors and plugs must securely fit and be of matching type.
4.1.2. Controls and indicators
Verify that controls and indicators do not show any damage and check during the performance test that they
are working properly.
4.1.3. Labels
Verify that all the required labels (certification of date of manufacture, serial number, etc.) are properly affixed to
certified components which have been installed or replaced.
4.1.4. System mechanical performance
position, both horizontally and vertically, when slightly displaced by hand.
On the contrary the arm shall remain steady in work position when a larger displacement is applied.
Before dismounting the system, move the arms in various positions to check for noise or binding problems.
When the frictioning of the arm and Tubehead assembly is well adjusted, the arm must return in standby
