Gigabyte GA-X99-UD5 WIFI User Manual

- 101 - Unique Features
5-2-8 Ambient LED
GIGABYTE Ambient LED allows you to enable or change the display mode for the onboard audio LED and rear
panel I/O shield LED
(Note)
while in the Windows environment.
The Ambient LED Interface
Using Ambient LED
• Audio LED (display mode of the onboard audio LED):
Off -- Disables this function.
Still Mode -- The LED stays constantly on.
Beat Mode -- The brightness of the LED changes according to music rhythm.
Pulse Mode -- The brightness of the LED changes slowly and smoothly like breath.
• Rear panel LED (display mode of the rear panel I/O shield LED)
(Note)
:
Off -- Disables this function.
On -- The LED will light and follow the behavior of the onboard audio LED.
(Note) ThisfunctiononlyworksformotherboardswithanI/OshieldthathasaudioLED.

Gigabyte GA-X99-UD5 WIFI Specifications

General

Non-ECC	Yes
Memory channels	Quad-channel
Memory slots type	DIMM
Number of memory slots	8
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2666, 2800, 3000 MHz
Processor socket	LGA 2011 (Socket R)
Processor manufacturer	Intel
Compatible processor series	Intel Core i7, Intel Core i7 Extreme Edition
USB 2.0 connectors	4
Number of SATA connectors	10
Number of Parallel ATA connectors	-
USB 3.2 Gen 1 (3.1 Gen 1) connectors	6
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA, SATA II, SATA III
PS/2 ports quantity	1
eSATA ports quantity	0
USB 2.0 ports quantity	2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® X99
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	Extended ATX
Parallel processing technology support	2-Way CrossFireX, 2-Way SLI, 3-Way CrossFireX, 3-Way SLI, 4-Way CrossFireX, 4-Way SLI
PCI Express x1 slots	3
BIOS type	UEFI
ACPI version	5.0

Weight and Dimensions

Depth	259 mm
Width	305 mm
