Goodwe GW10K-ET User Manual

1
01 About This ManualUser Manual V1.1-2022-12-20
1 About This Manual
1.1 Applicable Model
1.2 Target Audience
This manual describes the product information, installation, electrical connection,
commissioning, troubleshooting and maintenance. Read through this manual before
installing and operating the product. All the installers and users have to be familiar with the
product features, functions, and safety precautions. This manual is subject to update without
notice. For more product details and latest documents, visit https://en.goodwe.com.
This manual applies to trained and knowledgeable technical professionals only. The technical
personnel has to be familiar with the product, local standards, and electric systems.
This manual applies to the listed inverters below:
• GW5KL-ET
• GW6KL-ET
• GW8KL-ET
• GW10KL-ET
• GW5K-ET
• GW6.5K-ET
• GW8K-ET
• GW10K-ET
• GW5KN-ET
• GW6.5KN-ET
• GW8KN-ET
• GW10KN-ET
• GW5K-BT
• GW6K-BT
• GW8K-BT
• GW10K-BT
ET Series (Hybrid Inverter)
BT Series (AC-Coupled Inverter)

Goodwe GW10K-ET Specifications

General

Model	GW10K-ET
Max. DC Input Voltage	1000 V
Number of MPPTs	2
Rated AC Output Power	10000 W
Max. AC Output Power	11000 VA
Frequency	50 Hz / 60 Hz
Efficiency	98.3%
Dimensions	516 x 415 x 180 mm
Weight	25 kg
Max. DC Input Power	13000 W
Start Voltage	180 V
MPPT Voltage Range	200V - 1000V
Number of MPP Trackers	2
Max. Short Circuit Current per MPPT	15 A
Nominal AC Output Power	10000 W
Max. AC Apparent Power	11000 VA
Nominal AC Voltage	230 V / 400 V
Nominal Grid Frequency	50 Hz / 60 Hz
THDi	<3%
DC Switch	Yes
Protection Class	IP65
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Convection
Rated Output Power	10000 W
Grid Frequency	50 Hz / 60 Hz
Max. Efficiency	98.3%
Noise Level	<30 dB
Protection Degree	IP65
Type	Three Phase
AC Voltage Range	180V - 280V
Power Factor	0.8 leading - 0.8 lagging
Rated Grid Voltage	230 V
