Goodwe GW10K-ET User Manual

61
10 Technical Parameters
User Manual V1.1-2022-12-20
10 Technical Parameters
10.1 Technical Parameters - ET/ET Plus Series
Technical Parameters GW5KL-ET GW6KL-ET GW8KL-ET GW10KL-ET
Battery Input Data
Battery Type Li-Ion Li-Ion Li-Ion Li-Ion
Nominal Battery Voltage (V) 500 500 500 500
Battery Voltage Range (V) 180 ~ 600 180 ~ 600 180 ~ 600 180 ~ 600
Max. Continuous Charging Current
(A)
25 25 25 25
Max. Continuous Discharging
Current (A)
25 25 25 25
Max. Charge Power (W) 7,500 7,800 9,600 10,000
Max. Discharge Power (W) 7,500 7,800 9,600 10,000
PV String Input Data
Max. Input Power (W) 6,650 7,980 10,640 13,300
Max. Input Voltage (V)
*1
1000 1000 1000 1000
MPPT Operating Voltage Range (V)
*2
200 ~ 850 200 ~ 850 200 ~ 850 200 ~ 850
MPPT Voltage Range at Nominal
Power (V)
240 ~ 850 285 ~ 850 260 ~ 850 320 ~ 850
Start-up Voltage (V) 180 180 180 180
Nominal Input Voltage (V) 620 620 620 620
Max. Input Current per MPPT (A) 12.5 12.5 12.5/22 12.5/22
Max. Short Circuit Current per MPPT
(A)
15.2 15.2 15.2/27.6 15.2/27.6
Max. Backfeed Current to The Array
(A)
0 0 0 0
Number of MPP Trackers 2 2 2 2
Number of Strings per MPPT 1 1 1/2 1/2
AC Output Data (On-grid)
Nominal Apparent Power Output to
Utility Grid (VA)
5,000 6,000 8,000 10,000
Max. Apparent Power Output to
Utility Grid (VA)
*2
5,500 6,600 8,800 11,000
Nominal Apparent Power from
Utility Grid (VA)
10,000 12,000 15,000 15,000
Max. Apparent Power from Utility
Grid (VA)
10,000 12,000 15,000 15,000
