Goodwe SMT Series User Manual

User Manual V1.3-2023-01-31
10 Technical Parameters
51
Technical Data GW25K-MT GW29.9K-MT GW30K-MT GW36K-MT
AC Grid Frequency Range
(Hz)
47.5~51.5/57~61.8
Max. Output Current (A) 40.0 43.3 48.0 53.3
Max. Output Fault Current
(Peak and Duration)(A)
160@2.8μs
Inrush Current (Peak and
Duration) (A)
60@1.5ms
Nominal Output Current (A) 36.1 43.2 43.3 52.0
Output Power Factor ~1 (Adjustable from 0.8 leading to 0.8 lagging)
Max. Total Harmonic
Distortion
<3%
Maximum Output
Overcurrent Protection (A)
109
Eciency
Max. Eciency 98.7% 98.8% 98.8% 98.8%
European Eciency 98.4% 98.5% 98.5% 98.5%
Protection
PV String Current Monitoring Integrated
PV Insulation Resistance
Detection
Integrated
Residual Current Monitoring Integrated
PV Reverse Polarity
Protection
Integrated
Anti-islanding Protection Integrated
AC Overcurrent Protection Integrated
AC Short Circuit Protection Integrated
AC Overvoltage Protection Integrated
DC Switch Integrated
DC Surge Protection Type III (Type II Optional)
AC Surge Protection Type III (Type II Optional)
AFCI Optional
Remote Shutdown Optional
PID Recovery Optional
