Gree GC201306 -1 User Manual

Super Free Match
Service Manual
PRODUCT
9
¾ U-cool
Model
GWH(07)UA-K
3DNA1B/I
GWH(09)UA-K
3DNA1B/I
GWH(12)UB-K
3DNA1B/I
GWH(18)UC-K
3DNA1B/I
Cooling kW 2.1 2.6 3.5 5.3
Capacity
Heating kW 2.6 2.8 3.8 5.8
Power supply V-Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50 220~240-1-50
Motor power input kW 0.03 0.03 0.04 0.06
m3/h 450 450 560 850
Air flow volume
CFM 265 265 330 500
Sound pressure level
(SH/H/MH/M/ML/L/SL)
dB(A)
37/35/32/30/28/
26/24
38/35/32/30/28/
26/25
39/37/34/31/29/
27/26
44/40/37/35/33/
31/28
Output kW 0.01 0.01 0.02 0.025
Fan motor
Running
current
A 0.136 0.136 0.2 0.31
Gas inch 3/8″(Φ9.52mm) 3/8″(Φ9.52mm) 3/8″(Φ9.52mm) 1/2″(Φ12.7mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm)
Connecting
pipe
Connection method
Flare
Connection
Flare
Connection
Flare
Connection
Flare
Connection
External dia. mm Φ20 Φ20 Φ20 Φ20
Drain pipe
Thickness mm 1.5 1.5 1.5 1.5
Outline
dimension
W×D×H mm 860×153×299 860×153×299 896×159×320 998×178×340
Package
dimension
W×D×H mm 944×247×386 944×247×386 973×255×403 1083×283×428
Net Weight/ Gross weight kg 9.5/12.5 9.5/12.5 10/13 14.0/17.0
20'GP 324 324 279 216
40' GP 666 666 585 440
Loading quantity
40' HQ 740 740 650 495
Notes:
a. The rated cooling capacity data is measured under the following work condition: Indoor Temperature is 27℃
DB, 19℃WB. Outdoor Temperature is 35℃DB. The rated heating capacity data is measured under the following
work condition: Indoor Temperature is 20℃DB. Outdoor Temperature is 7℃DB, 6℃WB.
b. The data will change with the change of products. Refer to those parameters listed on nameplate.
c. Noise was tested in semi-silenced room, so the actual noise value will be a little higher for change of ambient.
