Super Free Match
Service Manual
MAINTENANCE
150
5 THE RESISTANCES OF COMMON TEMPERATURE SENSORS
5.1 15 KΩ
Temp.
（℃）
Resistance
(kΩ)
Voltage
(15K/5V)
Voltage
(15K/3.3V）
Temp.
（℃）
Resistance
(kΩ)
Voltage
(15K/5V)
Voltage
(15K/3.3V）
-20 144.000 0.472 0.311 20 18.750 2.222 1.467
-19 138.100 0.490 0.323 21 17.930 2.278 1.503
-18 128.600 0.522 0.345 22 17.140 2.334 1.540
-17 121.600 0.549 0.362 23 16.390 2.389 1.577
-16 115.000 0.577 0.381 24 15.680 2.445 1.613
-15 108.700 0.606 0.400 25 15.000 2.500 1.650
-14 102.900 0.636 0.420 26 14.360 2.554 1.686
-13 97.400 0.667 0.440 27 13.740 2.610 1.722
-12 92.220 0.699 0.462 28 13.160 2.663 1.758
-11 87.350 0.733 0.484 29 12.600 2.717 1.793
-10 82.750 0.767 0.506 30 12.070 2.771 1.829
-9 78.430 0.803 0.530 31 11.570 2.823 1.863
-8 74.350 0.839 0.554 32 11.090 2.875 1.897
-7 70.500 0.877 0.579 33 10.630 2.926 1.931
-6 66.880 0.916 0.605 34 10.200 2.976 1.964
-5 63.460 0.956 0.631 35 9.779 3.027 1.998
-4 60.230 0.997 0.658 36 9.382 3.076 2.030
-3 57.180 1.039 0.686 37 9.003 3.125 2.062
-2 54.310 1.082 0.714 38 8.642 3.172 2.094
-1 51.590 1.126 0.743 39 8.297 3.219 2.125
0 49.020 1.172 0.773 41 7.653 3.311 2.185
1 46.800 1.214 0.801 42 7.352 3.355 2.215
2 44.310 1.265 0.835 43 7.065 3.399 2.243
3 42.140 1.313 0.866 44 6.791 3.442 2.272
4 40.090 1.361 0.899 45 6.529 3.484 2.299
5 38.150 1.411 0.931 46 6.278 3.525 2.326
6 36.320 1.461 0.965 47 6.038 3.565 2.353
7 34.580 1.513 0.998 48 5.809 3.604 2.379
8 32.940 1.564 1.033 49 5.589 3.643 2.404
9 31.380 1.617 1.067 50 5.379 3.680 2.429
10 29.900 1.670 1.102 51 5.179 3.717 2.453
11 28.510 1.724 1.138 52 4.986 3.753 2.477
12 27.180 1.778 1.174 53 4.802 3.787 2.500
13 25.920 1.833 1.210 54 4.625 3.822 2.522
14 24.730 1.888 1.246 55 4.456 3.855 2.544
15 23.600 1.943 1.282 56 4.294 3.887 2.566
16 22.530 1.998 1.319 57 4.139 3.919 2.586
17 21.510 2.054 1.356 58 3.990 3.949 2.607
18 20.540 2.110 1.393 59 3.848 3.979 2.626
19 19.630 2.166 1.429 60 3.711 4.008 2.646
