94
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No.
Description
Part Code
QtyGWH18QD-K3DNA5E/I
Product Code CB425N07100
1 Front Panel 2002266901S01 1
2 Display Board 30565260 1
3 Filter Sub-Assy 11122089 2
4 Decorative Board 00000200023 1
5 Front Case 2002248401 1
6 Guide Louver 1051273402 1
7 Axile Bush 10542036 2
8 Air Louver(Manual) 10512732 3
9 Helicoid tongue 26112512 1
10 Left Axile Bush 10512037 1
11 Rear Case assy 22202571 1
12 Rubber Plug (Water Tray) 76712012 1
13 O-Gasket sub-assy of Bearing 7651205102 1
14 Ring of Bearing 26152025 1
15 Evaporator Support 24212177 1
16 Evaporator Assy 01100100020 1
17 Cross Flow Fan 10352060 1
18 Fan Motor 1501214502 1
19 Motor Press Plate 26112511 1
20 Wall Mounting Frame 01362026 1
21 Connecting pipe clamp 2611218801 1
22 Crank 73012005 1
23 Stepping Motor 1521240212 1
24 Drainage hose 05230014 1
25 Electric Box Assy 10000204564 1
26 Lower Shield of Electric Box 01592139 1
27 Electric Box 20112211 1
28 Jumper 4202021912 1
29 Main Board 30145099 1
30 Shield Cover of Electric Box 01592139 1
31 Electric Box Cover 20112209 1
32 Terminal Board 42011233 1
33 Decorative Board 2425201726 1
34 Screw Cover 2425201726 3
35 Electric Box Cover2 20112210 1
36 Connecting Cable 4002052317 0
37 Remote Controller 30510474 1
38 Cold Plasma Generator 1114001602 1
39 Detecting plate(WIFI ) 30110144 1
To Next Page
